50VDC Power Supply full kit
50V 7.5A full kit power supply
$141.00
This power supply uses 1 Mean well LRS-350-48 power supplies to provide 7.5A. Front panel on the left has a 1A plug with 0-1A Panel meter for adjusting amplifier BIAS. The center has a digital volt meter and ammeter with a 7.5 Power Pole plug. The 1A side uses a rocker switch to enable or disable the 1A Panel meter.
Enclosure cooling is provided by 2 fans, one blowing in the other blowing out. An off the shelf regulator is mounted to PCB that drops the 50V down to around 12V. The voltage can be set to a quiet fan speed of your choice.
The AC plug on back cover also has a switch similar to a desk top computer.
The enclosure is a plastic Hammond enclosure, 1598J, available in black or gray.
If your running the Potentia 100 then only one Mean well supply is needed.
Multus SDR will Provide the internal PCB to mount the supplies, along with front and back end plates. The brackets, hardware and wiring for the power supply will provided.
Meanwell 48V power supply not included
Enclosure cooling is provided by 2 fans, one blowing in the other blowing out. An off the shelf regulator is mounted to PCB that drops the 50V down to around 12V. The voltage can be set to a quiet fan speed of your choice.
The AC plug on back cover also has a switch similar to a desk top computer.
The enclosure is a plastic Hammond enclosure, 1598J, available in black or gray.
If your running the Potentia 100 then only one Mean well supply is needed.
Multus SDR will Provide the internal PCB to mount the supplies, along with front and back end plates. The brackets, hardware and wiring for the power supply will provided.
Meanwell 48V power supply not included
- Availability: On Back order
